100 Watt Mono Solar Module
Price
Rs. 9,400
Rs. 7,990
In stock
Ready to ship from Kathmandu
Free delivery
And professional install
Genuine warranty
Backed by manufacturer
30-day returns
Money-back guarantee
At a glance
100 Wp ±3%
Rated Power (Pmax)
12 V DC
Nominal System Voltage
10 A
Maximum Series Fuse Rating
About —
Built for daily use,
designed to last.
The ULTRA 100 Watt Mono Solar Module is a 36-cell monocrystalline PV panel with a 12V DC nominal system voltage, used for lighting systems, battery charging, and off-grid setups. It is rated at 100Wp ±3%, with 18.0V Vmp, 5.56A Imp, 22.14V Voc, and 5.84A Isc. It uses an anodized aluminium frame, tempered low-iron solar glass, and a weatherproof junction box with bypass diodes.
Datasheet —
Full
specifications.
Every spec we publish is sourced from the manufacturer and verified by our engineering team.
20 entries
- Brand
- ULTRA QUALITY
- Type
- Monocrystalline Solar Panel
- Rated Power (Pmax)
- 100 Wp ±3%
- Nominal System Voltage
- 12 V DC
- Solar Cell Type
- Monocrystalline Silicon
- Number of Cells
- 36 cells
- Maximum Power Voltage (Vmp)
- ≈18.0 V
- Maximum Power Current (Imp)
- ≈5.56 A
- Open Circuit Voltage (Voc)
- ≈22.14 V
- Short Circuit Current (Isc)
- ≈5.84 A
- Maximum System Voltage
- 1000 V DC
- Maximum Series Fuse Rating
- 10 A
- Module Dimensions
- Approx. 810 × 710 × 30 mm
- Frame Material
- Anodized Aluminum Frame
- Front Glass
- Tempered Low-Iron Solar Glass
- Junction Box
- Weatherproof with bypass diodes
- Weight
- Around 6–8 kg
- Operating Temperature
- -40°C to +85°C
- Standard Test Conditions (STC)
- 1000 W/m², AM1.5, 25°C
- Power Tolerance
- 0 to +3%
Fine print —
Terms &
additional info.
Terms & conditions
- 01Higher efficiency compared to poly panels
- 0212V DC nominal output for simple system integration
- 03Continues generating useful electricity in low-light and cloudy conditions
- 04Weatherproof junction box with bypass diodes
- 05Anodized aluminum frame with tempered low-iron solar glass
