150 Watt Mono Solar Module
Price
Rs. 13,500
Rs. 11,475
In stock
Ready to ship from Kathmandu
Free delivery
And professional install
Genuine warranty
Backed by manufacturer
30-day returns
Money-back guarantee
At a glance
20 years
Warranty
150 W
Rated Power (Pmax)
18.0 V
Maximum Power Voltage (Vmp)
About —
Built for daily use,
designed to last.
The ULTRA 150 Watt Mono Solar Module is a 36-cell monocrystalline PV panel with a 12V DC nominal output, intended for battery charging, lighting systems, and small solar projects. It is rated at 150W peak with ±3% tolerance, 18.0V Vmp, 8.33A Imp, 22.14V Voc, and 8.84A Isc. Construction includes 3.2 mm tempered glass, an anodized aluminium frame, a TPT backsheet, and an IP65/IP68 junction box.
Datasheet —
Full
specifications.
Every spec we publish is sourced from the manufacturer and verified by our engineering team.
24 entries
- Brand
- ULTRA QUALITY
- Type
- Monocrystalline Solar Panel
- Rated Power (Pmax)
- 150 W
- Power Tolerance
- ±3% (listed as 0 to +3% / +5%)
- Nominal Output
- 12 V DC
- Cell Type
- Mono-crystalline silicon
- Number of Cells
- 36 cells
- Module Efficiency
- Around 14–19%
- Maximum Power Voltage (Vmp)
- 18.0 V
- Maximum Power Current (Imp)
- 8.33 A
- Open Circuit Voltage (Voc)
- 22.14 V
- Short Circuit Current (Isc)
- 8.84 A
- Maximum System Voltage
- 1000 V DC
- Maximum Series Fuse Rating
- 10 A
- Front Glass
- 3.2 mm tempered glass
- Frame
- Anodized aluminum alloy
- Back Sheet
- Weather-resistant TPT backsheet
- Junction Box
- IP65 / IP68 rated
- Cable
- 4 mm² solar cable
- Dimensions
- Approx. 1480 × 670 × 35 mm
- Weight
- Around 10–12 kg
- Operating Temperature
- -40°C to +85°C
- Nominal Module Operating Temperature (NMOT)
- ~47°C
- Warranty
- 20 years
Fine print —
Terms &
additional info.
Terms & conditions
- 0120-year warranty
- 02Advanced mono-crystalline cells for high conversion efficiency
- 03Consistent energy output in low-light conditions
- 04IP65 / IP68 rated junction box
- 05Anodized aluminum alloy frame and weather-resistant TPT backsheet
- 06Compatible with systems up to 1000V maximum voltage
- 0710A series fuse rating for added protection
