Solar Panels
01 / 04Solar Panels —
50 Watt Mono Solar Module
Price
Rs. 5,500
Rs. 4,400
In stock
Ready to ship from Kathmandu
Free delivery
And professional install
Genuine warranty
Backed by manufacturer
30-day returns
Money-back guarantee
At a glance
25 years
Warranty
50 Wp
Rated Power (Pmax)
12 V DC
Nominal System Voltage
About —
Built for daily use,
designed to last.
The ULTRA 50 Watt Mono Solar Module is a 36-cell monocrystalline photovoltaic panel rated at 50 Wp (±3%) for a 12V DC nominal system. It has an open-circuit voltage around 22.14V, a short-circuit current of 2.92A and an optimum current of 2.78A, and supports a 1000V maximum system voltage with a 10A series fuse. The anodized aluminium frame, tempered low-iron glass and weatherproof junction box suit small off-grid and home solar systems.
Datasheet —
Full
specifications.
Every spec we publish is sourced from the manufacturer and verified by our engineering team.
22 entries
- Brand
- ULTRA
- Product Type
- Monocrystalline Solar Panel
- Rated Power (Pmax)
- 50 Wp
- Power Tolerance
- ±3%
- Nominal System Voltage
- 12 V DC
- Solar Cell Type
- Monocrystalline Silicon
- Number of Cells
- 36 Cells
- Maximum Power Voltage (Vmp)
- ≈ 18.0 – 19.8 V
- Maximum Power Current (Imp)
- ≈ 2.5 – 2.8 A
- Open Circuit Voltage (Voc)
- ≈ 22 – 23 V (22.14 V)
- Short Circuit Current (Isc)
- ≈ 2.7 – 2.9 A (2.92 A)
- Optimum Current
- 2.78 A
- Maximum System Voltage
- 1000 V DC
- Maximum Series Fuse Rating
- 10 A
- Module Dimensions
- Approx. 570 × 540 × 25 mm (varies by model)
- Frame Material
- Anodized Aluminum Frame
- Front Glass
- Tempered Low-Iron Solar Glass
- Junction Box
- Weatherproof with bypass diode
- Weight
- Around 3–4 kg
- Operating Temperature
- −40°C to +85°C
- Standard Test Conditions (STC)
- 1000 W/m², AM1.5, 25°C
- Warranty
- 25 years
Fine print —
Terms &
additional info.
Terms & conditions
- 01High-efficiency mono-crystalline cells
- 02Consistent energy output even in low-light conditions
- 03Compact design for easy installation
- 04Suitable for 12V and 24V solar systems
- 05Weatherproof junction box with bypass diode
- 0625-year warranty
