Solar Panels
01 / 04Solar Panels —
80 Watt Mono Solar Module
Price
Rs. 8,000
Rs. 6,800
In stock
Ready to ship from Kathmandu
Free delivery
And professional install
Genuine warranty
Backed by manufacturer
30-day returns
Money-back guarantee
At a glance
80 Wp
Rated Power (Pmax)
12 V DC
Nominal Voltage
10 A
Maximum Series Fuse Rating
About —
Built for daily use,
designed to last.
The ULTRA 80 Watt Mono Solar Module is a 36-cell monocrystalline PV panel with a 12V DC nominal output, suited to rural electrification, lighting systems, battery charging, and off-grid solar setups. It is rated at 80Wp with ±3% tolerance, delivering 18.0V operating voltage and 4.44A current, with 22.14V open circuit voltage and 4.66A short circuit current. The panel uses an anodized aluminium frame, tempered low-iron glass, and an IP65 junction box with bypass diode.
Datasheet —
Full
specifications.
Every spec we publish is sourced from the manufacturer and verified by our engineering team.
20 entries
- Brand
- ULTRA QUALITY
- Type
- Monocrystalline Solar Panel
- Rated Power (Pmax)
- 80 Wp
- Power Tolerance
- ±3%
- Nominal Voltage
- 12 V DC
- Solar Cell Type
- Monocrystalline Silicon
- Number of Cells
- 36 cells
- Maximum Power Voltage (Vmp)
- 18.0 V (spec list: ≈18.0–19.0 V)
- Maximum Power Current (Imp)
- 4.44 A (spec list: ≈4.2–4.5 A)
- Open Circuit Voltage (Voc)
- 22.14 V (spec list: ≈21.6–23.9 V)
- Short Circuit Current (Isc)
- 4.66 A (spec list: ≈4.2–4.9 A)
- Maximum System Voltage
- 1000 V DC
- Maximum Series Fuse Rating
- 10 A
- Frame Material
- Anodized Aluminum Frame
- Front Glass
- Tempered Low-Iron Solar Glass
- Junction Box
- Weatherproof IP65 rated with bypass diode
- Module Dimensions
- Approx. 735 × 580 × 30 mm – 770 × 665 × 30 mm
- Weight
- Around 5–6 kg
- Operating Temperature
- -40°C to +85°C
- Standard Test Conditions (STC)
- 1000 W/m², AM1.5, 25°C
Fine print —
Terms &
additional info.
Terms & conditions
- 0112V DC nominal output compatible with standard solar batteries and inverters
- 02Advanced mono-crystalline technology for stable output
- 03Performs in low-light and cloudy conditions
- 04Weatherproof IP65 rated junction box with bypass diode
- 05Anodized aluminum frame with tempered low-iron solar glass
